NXH80T120L3Q0S3G

Name: NXH80T120L3Q0S3G
Brand: NXH80T120L3Q0S3G
SKU: NXH80T120L3Q0S3G
Rating: 4.8 (148 reviews)

Product Details

Category:

Discrete Semiconductor Products Transistors IGBTs IGBT Modules

Current - Collector (Ic) (Max):

75 A

Product Status:

Active

Mounting Type:

Chassis Mount

Package:

Tray

Series:

Package / Case:

Module

Vce(on) (Max) @ Vge, Ic:

2.4V @ 15V, 80A

Voltage - Collector Emitter Breakdown (Max):

1200 V

Supplier Device Package:

20-PIM/Q0PACK (55x32.5)

Mfr:

Onsemi

Operating Temperature:

-40°C ~ 175°C (TJ)

Current - Collector Cutoff (Max):

300 µA

IGBT Type:

Trench Field Stop

Power - Max:

188 W

Input:

Standard

Input Capacitance (Cies) @ Vce:

18.15 NF @ 20 V

Configuration:

Half Bridge

NTC Thermistor:

Yes

Payment & Shipping Terms

Stock

In Stock

Shipping Method

LCL, AIR, FCL, Express

Description

PIM GENERATION3 Q0PACK 1200V, 80

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Product Description

IGBT Module Trench Field Stop Half Bridge 1200 V 75 A 188 W Chassis Mount 20-PIM/Q0PACK (55x32.5)
